Specifications
| Current Rating | 1A | Voltage Rating | AC 50 V |
| Contact Resistance | 20mΩMax. Initial | Operating Temperature | -40℃~+105℃ |
| Insulation Resistance | 1000MΩ | Withstanding Voltage | 500V AC/60S |
| Contact Material | Copper Alloy | Housing Material | High Temperature Thermoplastic. UL 94V-0 |
| Max. Processing Temperature | 260℃ for 10 Seconds |
Mating With
Straight
PNZ
QOZ
Right Angle
QOT
SMT
Top Entry
SPNZ
