Specifications
| Current Rating | 3A | Voltage Rating | AC 125 V |
| Contact Resistance | 20mΩMax. Initial | Operating Temperature | -40℃~+105℃ |
| Insulation Resistance | 1000MΩ | Withstanding Voltage | 500V AC/60S |
| Contact Material | Copper Alloy | Housing Material | Thermoplastic. UL 94V-0 |
Mating With
Straight
XHCY
XG
XHY-XXS
Right Angle
XHY-XXR
SMT
Side Entry
SNXHY
