Specifications
| Current Rating |
3 AMPS | Rating Voltage | 30V AC/DC |
| Operating Temperature | -40C~+105C | Contact Retention Force | 300g min. per contact |
| Contact Material | Copper Alloy | Housing Material | LCP, UL 94V-0 |
| Durability | 50 cycles min. | Contact Resistance | 20m ohms MAX. Initial. |
| Dielectric Withstanding Voltage | 500V AC rms./minute | Insulation Resistance | 5000 Megohms Min. |
| High Temperature Point | 270土5°C;7s +2s/-0s |
